Missions tracked at Deep Space Station 51 at Hartbeesthoek

Plaques still to be found at HartRAO commemorate some of the spacecraft that were tracked. Images of these are used below to illustrate some of the missions with which DSS 51 was involved.

Rangers to the Moon

Ranger VII
Click on the image for large version

In preparation for landing men on the Moon, several series of unmanned spacecraft were sent to explore it. First were the Rangers, designed simply to take photographs and send them back to Earth. These spacecraft flew straight towards the Moon until they crashed into the surface. Ranger I was the first mission for the NASA Deep Space Stations. Launched on 23 August 1961, it did not get beyond Earth orbit owing to the failure of the Agena second stage.

The first successful mission was Ranger VII, and two more successful missions followed. Ranger VII sent back 4308 photos before it impacted the Moon on 31 July 1964.

Surveyors to the Moon

Surveyor VII
Click on the image for large version

The Surveyor series were much more advanced. They soft-landed on the Moon just like Apollo was to do.

Lunar Orbiters

Lunar Orbiter III
Click on the image for large version

The moon had to be mapped at high resolution to see where the Apollos could land. This was done with the Lunar Orbiter series of spacecraft.

Apollo - Man on the Moon

Apollo 15
Click on the image for large version

Finally, after all the careful preparations, the Apollo spacecraft took men to the Moon for the first time.

Mariners to Venus

While Apollo was going on, the rest of the solar system was not neglected.

Mariner V
Click on the image for large version

Mariner V was an early spacecraft sent to explore Venus. However, NASA had more luck with their Mars spacecraft than with their probes to Venus, where Soviet spacecraft were more succesful.

Mariners to Mars

Mariner IV obtained the first closeup photographs of Mars in a fly-by during 1965. The NASA Mission Report notes that on July 14: "Mariner-Mars encounter began properly with an event on Earth, not one in space. The Johannesburg DSIF station transmitted a command to turn on the TV scan platform, anticipating by about an hour a similar on-board command from the CC&S (Central Computer and Sequencer). This was the first of eleven ground commands transmitted to the spacecraft during encounter operations."

Mariner IV first picture

The images obtained by the TV camera were recorded on tape and transmitted back to Earth after the encounter. The very first picture was received here at Hartebeesthoek on July 15 1965, starting at 13:01:58 UT, when Mars was nearly overhead at Johannesburg. This picture is shown below. These pictures were also the first pictures of another planet to be taken by a spacecraft. The data were transmitted back to Earth at a rate of 8.33 bits per second, and the strength of the received signal was 10-19 Watts. The picture above was the very first received from Mars.

Mariner IV craters

Image number 11 from Mariner IV clearly shows that Mars is cratered, and showed no signs of Percival Lowell's "canals".

Mariner IV plaque
Click on the image for large version

The Mariner IV plaque in the foyer of the Control Building commemorates these first pictures from a spacecraft at Mars.

Mariner VI colour picture

Mariner VI was able to send back colour pictures of Mars.

Mariner VI
Click on the image for large version

Mariner VI is commemorated in this plaque.

Pioneers Exploring Interplanetary Space

Pioneer VIII
Click on the image for large version

The Pioneer series of spacecraft were designed to investigate conditions in space between the planets.

For more information, see the History of the Deep Space Network at the Jet Propulsion Laboratory.
